PRFL-22-I-WMPRFL-22-I-WM
New Product
Profile 22 Indirect Wall Mount
Crafted from precision-extruded aluminum with welded end caps, PRFL-22-I-WM is a sleek, ADA-compliant linear wall luminaire that seamlessly integrates into modern commercial environments. Ideal for office spaces, classrooms, healthcare facilities, and other high-traffic interiors, this fixture provides exceptional, energy-efficient general illumination.
Available as individual fixtures up to 8' or in continuous row configurations, the versatile design pairs with suspended, surface-mounted, and recessed PRFL-22Â installations. Compatible with a variety of advanced Smart Lighting technologies, including daylight harvesting, occupancy sensing, and wireless controls, to optimize energy use and comfort.
Resources
CONSTRUCTION: Extruded aluminum housing, 20-gauge cold-rolled steel internal components.Â
REFLECTOR: Highly reflective baked white enamel with pre-finished reflective LED tray.Â
OPTICS: Frosted acrylic, 1" and 2" drop lens (square) and 1" and 2" drop lens (round).
LED: Static white LED modules in 27/30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW, RGBWW, Tunable White, and Dim-to-Warm options available; field replaceable.Â
DRIVER: Standard driver is Class 2 AOC 0-10V to 1%, Dim-to-Off available. 120/277V input, PF > 90%, THD < 20 @ 120V. DMX, DALI & Lutron protocols available. All drivers are prewired for connection to the control system (by others) and are field-replaceable.Â
MOUNTING: Mounting is wall-mounted to a single-gang junction box.
FINISH: Housing and components finished in baked white enamel.
CERTIFICATION: cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America, I.B.E.W., BAA compliant, Declare Red List Approved. ADA Compliant.
Mounting
- Wall
Distribution
- Indirect
Ratings & Compliance
- ADA
- Buy American Act (BAA)
- Damp
- Declare
- Made in America
- Red List Approved
Special Programs
- Rapid Ship
Emergency Options
- DC Central Battery
- EM Circuit
- Emergency Battery Backup
- GTD
- Integral EM Battery
Controls Options
- Circadian Lighting
- Daylight Occupancy Sensor
- Daylight Sensor
- Human Centric Lighting
- Motion Sensor
- Occupancy Sensor
- Wired Control
- Wireless Control
Dimming Protocol
- 0-10 V
- Bluetooth Wireless
- Casambi Wireless
- D4i
- DALI
- DMX
- ELV (Trailing Edge)
- Forward Phase
- Hi-lume
- Lutron
- Lutron Athena
- Lutron EcoSystem
- Lutron LD2
- Lutron Vive
- Step-Dimming
- Two Wire
Dimming Range
- 0-100%
Dynamic LED Color
- BIOS
- BIOS Dynamic
- BIOS SkyBlue
- BIOS Tunable White
- Dim to Warm
- RGB
- RGB Tunable
- RGBA
- RGBW
- Tunable White
- Variable White
Availability
- Quick Ship
CCT
- 1800K
- 2000K
- 2100K
- 2200K
- 2300K
- 2400K
- 2700K
- 3000K
- 3500K
- 4000K
- 4100K
- 4500K
- 5000K
- 5300K
- 5500K
- 5700K
- 6000K
- 6500K
CRI
- 80 CRI
- 90 CRI
- 92 CRI
- 95 CRI
Circuit
- Single Circuit
Color / Finish
- Anti-Microbial White
- Custom
- White
Efficacy
- 110 lm/w
Integrated Brands
- Acuity nLight
- Avi-on
- BubblyNet
- Casambi
- Cooper Wavelinx
- Current NX
- Legrand
- Lutron Athena
- Lutron LD2
- Lutron Vive
- Philips EasySense
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- CSA
- ETL
- cULus
Materials
- Acrylic
- Aluminum
Shape
- Linear
Static LED Color
- Amber
- BIOS Static
- Blue
- Green
- Static
- White
Up/Down Ratio
- 100/0 (Up/Down)
Voltage
- 120-277 V
Warranty
- 5 yr
